Factory Lead Time

12 Weeks

Package / Case

8-SMD Module, 5 Leads

Mounting Type

PCB, Surface Mount

Voltage - Input (Nom)

5V

Power - Output (Max)

250mW

Power Dissipation (Max)

250mW

Operating Temperature

-40°C~105°C

Published

2014

Packaging

Tube

Series

ISK (0.25W)

Size / Dimension

0.50Lx0.33W x 0.29 H 12.7mmx8.3mmx7.3mm

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

5

ECCN Code

EAR99

Type

Isolated Module

Applications

ITE (Commercial)

Terminal Position

DUAL

Terminal Form

GULL WING

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Terminal Pitch

2.54mm

Depth

12.7mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

JESD-30 Code

R-XDMA-G5

Number of Outputs

1

Efficiency

79%

Voltage - Isolation

1.5kV

Voltage - Input (Max)

5.5V

Trim/Adjustable Output

NO

Current - Output (Max)

50mA

Output Power

250mW

Voltage - Output

5V

Current - Output 1

50mA

Max Input Voltage (DC)

5.5V

Min Input Voltage (DC)

4.5V

Features

SCP

Height

7.366mm

Width

8.3mm

REACH SVHC

Unknown

RoHS Status

ROHS3 Compliant
